Product overview

Industrial 4G wireless router is mainly used in data transmission business of industry , transparent data transmission, image transmission, equipment monitoring and wireless routing Internet access. Expanded applications include: GPS, etc. The uses an embedded high-performance CPU to effortlessly handle routing, single The SIM card is designed to process protocols and large amounts of data at high speed and stability, and can be matched with a variety of 4G industrial modules (WCDMA/EVDO/TD-SCDMA/TDD/FDD-LTE networks). Provide 10/100m Ethernet port, WIFI wireless interface, serial port, IO port and many other interfaces. Support WEB configuration mode, convenient and simple management, and support remote cloud control.

Product character

1. Adopt high-performance industrial wireless module;

2. Support (WCDMA/CDMA/TD-SCDMA) and 4G (FDD-LTE/TDD-LTE)

3. Adopt metal shell with protection grade of IP30;

4. Standard RJ45 (Ethernet) interface built-in lightning protection 3000V (nonstandard configuration needs to be customized);

5, wide voltage current input: DC7-35V/3A;

6. Support 2-channel analog input/control output with photoelectric isolation, which is applied to vehicle diagnosis and alarm, control vehicle flameout, etc. (Non-standard configuration needs to be customized);

7. Software and hardware watchdog anti-crash design, after the router is disconnected, it will automatically power off and restart to ensure stable and reliable operation of the equipment; 8, automatic detection of network disconnection, automatic restart of dialing failure, timing restart and other functions;

9. Serial port transparent transmission function. The command control mode can be entered through the serial port to control the router and ancillary equipment;

10. Support multiple DDNS dynamic domain name services;

11. Port mapping, DMZ host and other functions;

12. Support VPN (PPTP Client, L2TP Client);

13. Optional GNSS positioning module, supporting RTK technology, and supporting multiple satellite systems
