Software function

Access mode

DHCP/Static IP/PPPOE for 4G dial-up

Number of supported users

Wired: 253, wireless: 30

Operating system requirements

Windows XP/VISTA Linux 2.6 Windows 7 or later MAC OS: 10.3.7 or later

Browser requirements

Internet Explorer :6.0 or later Safari:1.2.4 or later Firefox:2.0.0.8 or later

Safety management

MAC filtering: disables the added MAC addresses

Set a firewall: prevent malicious attacks on computers on the LAN from the Internet

Access control: Controls the Internet access permissions of computers on the LAN

Port blocking: Prevents viruses from continuously launching connections through a port to prevent Dos attacks

System service

Virtual server: Set an internal server for Internet users to access

DMZ: If the open port of the virtual server to be set is uncertain, you can set it as a DMZ host

Port trigger: The wireless router can automatically open inward service ports based on the port used by the LAN to access the Internet

Serial port service: serial port data transmission, AT command control and other functions

Equipment management

Area Settings, restoring factory Settings, NTP server Settings, backing up system Settings, and restoring Settings from files

Software upgrade, remote management, reboot, password change

WLAN security mode

WPAPSK, wpa-psk, wpa2-psk, Open System, WPA2PSK(that is, wPA-psk and, WPA2 mixed modes), wPA2-psk mixed modes), WPA1WPA2(that is, WPA and

Hardware parameter

antenna

SMA external rotation of the inner hole

Wireless interface

IEEE802.11b/g/n

Operating frequency band

2400-2483.5MHz

WIFI transmission rate

300Mbps（MAX）

External interface

Reset key: 1

Indicator light: 4

Antenna interface: 1-4 (optional)

SIM card slot: 1

DC power port: 1

RS232/485 port: 1

LAN port: 2 (LAN1 is WAN/LAN adaptive)

WiFi data

802.11b: -86dBm at 11Mbps/CCK：+18 dBm

802.11g: -73dBm at 54Mbps/OFDM：+15.5dBm

802.11n: -66dBm at 300Mbps/HT40 MCS7：+15.5dBm

Supported frequency band (optional)

GN(Domestic - default)：FDD-LTE B1/3/5/8 TDD-LTE B38/39/40/41

Europe：FDD-LTE B1/3/5/7/8/20 TDD-LTE B38/39/40/41

North America(NA)：FDD-LTE B2/3/4/5/7/8/12/13/17/25/26/66 TDD-LTE B41

Global：FDD-LTE B1/2/3/4/5/7/8/17/20/28 TDD-LTE B38/39/40/41

Storage memory

Storage 8MB, memory 64MB

Power supply

Dc power supply: 12-24V/1A (optional voltage 12/24V)

Power consumption (current)

Less than 400mA

Overall dimension

Length width height: 97*78.2*25.1mm (without antenna interface)

Working environment

Operating temperature: -20°C ~ +70°C

Storage temperature: -40°C ~ +80°C

Humidity: 5%~95%, no condensation

Certification

CE、FCC、CCC
